Wire harness tapes | RT series Coroplast 835 X RT

Reverse tapes for flexible wire harness bundling
contact
Coroplast 835 X RT

Characteristics

  • Developed specifically to minimise the contact between adhesive and wire bundle allowing maximum flexibility of harness
  • For use in confined areas and limited installation spaces
  • Very good resistance to cold and heat
  • Good chemical resistance
  • Solvent-free adhesive
  • Resistance to ageing and rotting
  • Available in R (right) and L (left) versions
  • Perform final wrapping with tape wound onto itself
  • High sealing strength of the spiral wrapping (adhesive to adhesive)
  • Easy to tear by hand
  • Extremely heat-resistant
  • High abrasion resistance
  • Solvent-free acrylic adhesive
832 MPX RT 833 MPX RT 834 MPX RT 835 X RT 837 X RT 839 RT 8550 RT 880 X RT
CARRIER PA cloth PET laminate PA/ PET laminate PET cloth PET cloth PET cloth PET fleece PA velour
ADHESIVE Acrylic Acrylic Acrylic Acrylic Acrylic Synthetic rubber Synthetic rubber Acrylic
WIDTHS IN mm 35, 50 35, 50 35, 50 35, 50 35, 50 35, 50 35, 50 35, 50
THICKNESS IN mm 0.7 1.2 1.2 0.5 0.5 0.3 0.5 1.2
ABRASION CLASSES G E G E E C B E
SOUND DAMPENING CLASSES B D D B B A D E
HEAT RESISTANCE 125 125 125 150 150 125 105 125
